Scope of application

It is suitable for liquid fire with flash point higher than 60℃ in petrochemical industry and protective cooling of class A, B, C liquid and flammable gas storage devices.

enforce standards

GB 50084-2001 Code for design of automatic sprinkler systems

GB 50160-1992 Code for Fire Protection Design of petrochemical enterprises (1999 edition)

GB 50219-1995 Code for design of water spray fire extinguishing systems

GB 50316-2000 Specification for design of industrial metal pipes

GB/T 13912-2002 Metal coating Steel parts - Technical requirements and test methods for hot-dip galvanized coating

GB 50235-1997 Code for construction and acceptance of industrial metal pipeline works

GB 50236-1998 Code for construction and acceptance of welding works of field equipment and industrial pipelines

Design pressure

Rated working pressure at the nozzle: water curtain nozzle 0.15MPa~0.25MPa, water mist nozzle 0.35MPa(can be determined according to user requirements).

Type description
